Male Hose Adapter

Male Hose Adapter is a general hose adapter, which made in stainless steel 304 or 316L etc. Wellgreen sanitary fittings offer male hose adapters with NPT threaded, BSP threaded etc, all sanitary adapter fittings are made by CNC machine, our product is your idea choice for high purity service. Customized fabrication is available for us.

Sanitary Male Hose Adapters – Thread Hose Coupling
Size 1/2″ thru 4″
Material T304, T316L, en1.4301, en1.4404 etc.
Standard 3A, DIN, SMS, BS, ISO, RTJ, ISO etc.
End Connection
  • Male x Clamp
  • Male x Plain End
Surface Brushed finish, Descaled finish, Mirror polished
SEALING MATERIAL PTFE, EPDM, Buna-N, Silicone gaskets etc.
Application Food, Brewery, Beverage, Dairy, Pharmaceutical, Fine chemical, Cosmetic etc.
How to order *Part Name

*Dimension

*Material

*Quantity

*Standard / Sample / Drawing

*Polish requests



male hose adapter fitting

Dimension for Sanitary Male Hose Adapter – DIN – Thread Hose Coupling

Size D Dn G L
DN25 28 24 RD52×1/6 90
DN32 34 30 RD58×1/6 100
DN40 40 35 RD65×1/6 100
DN50 52 47 RD78×1/6 125
DN85 70 64 RD95×1/6 140
DN80 85 79 RD110×1/4 150
DN100 104 98 RD130×1/4 160



male hose adapter fitting

Dimension for Sanitary Male Hose Adapter – SMS – Thread Hose Coupling

Size D Dn G L
1″ 25.4 20 RD40×1/6 90
1 1/4″ 32 27 RD48×1/6 100
1 1/2″ 38.1 33 RD60×1/6 100
2″ 50.8 46 RD70×1/6 125
2 1/2″ 63.5 57.5 RD85×1/6 140
3″ 76.2 70 RD98×1/6 150
4″ 101.6 96 RD132×1/6 160



male hose adapter fitting

Dimension for Sanitary Male Hose Adapter – 3A – Thread Hose Coupling

Size D Dn G L
1″ 25.4 20 37.13×8Acme 90
1 1/2″ 38.1 33 50.65×8Acme 100
2″ 50.8 46 64.1×8Acme 125
2 1/2″ 63.5 57.5 77.6×8Acme 140
3″ 76.2 70 91.1×8Acme 150
4″ 101.6 96 119.25×8Acme 160



male hose adapter fitting

Dimension for Sanitary Male Hose Adapter – INCH – Thread Hose Coupling

Size D Dn G L
1″ 25.4 20 45.7×8TPIWHIT 90
1 1/2″ 38.1 33 58.4×8TPIWHIT 100
2″ 50.8 46 72.6×6TPIWHIT 125
2 1/2″ 63.5 57.5 85.4×6TPIWHIT 140
3″ 76.2 70 98.1×6TPIWHIT 150
4″ 101.6 96 123.8×6TPIWHIT 160

*All dimensions are in mm except specified.

*For more information and specification about Sanitary Adapter Fittings, please contact us here.
